Powerwall 48V 100AH 150AH 200AH Rechargeable Storage for Commercial Solar Power System Home 10kwh 20kwh Storage battery
|
Item No. |
LF25200-02 | LF51100-10 | LF51150-02 | LF51200-02 |
|
Battery Type |
LiFePO4 | LiFePO4 | LiFePO4 | LiFePO4 |
|
Nominal Voltage |
25.6V | 51.2V | 51.2V | 51.2V |
|
Nominal Capacity |
200Ah | 100Ah | 150Ah | 200Ah |
|
Charging Cut-off Voltage |
29.2V | 51.5V-54V | 58.4V | 58.4V |
|
Discharging Cut-off Voltage |
21.6V | 45V-54V | 40.8V | 40.8V |
|
Max. Cont. Charging/Discharging Current |
100A | 100A | 100A | 100A |
|
Max. Instantaneous Charge/Discharge Current |
200A | 100A | 200A | 200A |
|
Max. Number Of Parallel |
6 sets | 6 sets | 6 sets | 6 sets |
|
Cycle Life |
≥6000 | ≥6000 | ≥6000 | ≥6000 |
|
Product Size |
720*355*167mm | 530*485*175mm | 800*435*175mm | 800*551*175mm |
|
Weight |
30kg | 47kg | 60kg | 79kg |
| Warranty | 5 years | 5 years | 5 years | 5 years |
The product belongs to one of the series of household energy storage products that are independently designed and developed by us. It is used for energy storage and energy supply to household, commercial, UPS and other electrical equipment.
This product enjoys many merits: long cycle life, high safety standard from software protection to strong housing, exquisite looks, and easy installation, etc. It is widely used in energy storage system with off-grid inverters, grid-connected inverters and hybrid inverters.
-
Single Unit
-
2.Multi-Units in Parallel (4 sets as an example)Max. Number Of Parallel: 4 Sets
Master Pack and Slave Pack can be used as single unit as well as multi-units (in parallel) mode. The customer must inform supplier if multi-units mode is required.
Our Energy Storage Mobile Battery is designed to optimize the utilization of solar energy, providing a reliable and sustainable power source for residential and commercial applications. The Solar Energy Storage System features advanced lithium battery technology, ensuring long-lasting performance and durability.
With our Solar Lithium Battery System, users can store excess solar energy during the day and utilize it during peak hours or when sunlight is limited. This Solar Battery Storage solution offers a cost-effective and eco-friendly way to enhance energy independence and reduce reliance on the grid.
Experience the benefits of our Solar Battery Energy Storage System from ALLTOP, where innovation meets sustainability for a brighter and greener future.CONTACT US.
Match installation screw
We use K=K strong white carton outer package
Printing the product pictures on the boxes
