We are a leading manufacturer of solar power utilization and lighting systems

ALLTOP 1
ALLTOP 2
ALLTOP 3
ALLTOP 4
ALLTOP 5
ALLTOP 1
ALLTOP 2
ALLTOP 3
ALLTOP 4
ALLTOP 5

ALLTOP

Certification:
CE/ISO9001/RoHS/3C/CQC//UL/TUV
Delivery Time:
5-15 days
Payment Terms:
L/C, D/A, D/P, T/T, Western Union, Money Gram,
Service:
OEM/ODM Customized
Start Port:
guangzhou ,shenzhen, zhuhai
Supply Ability:
5000 PCS/Month
Inquiry
Company Advantages
1. The LED chips of ALLTOP are manufactured with solid-state technology. And the encapsulation technology has been updated and improved for many times to achieve better LED chip performance. Easy installation is the feature of the product
2. With all these features, this product does not need to be replaced frequently, saving a lot of maintenance resources and costs. Thanks to the adoption of the aluminum alloy, the product is waterproof
3. During the stage of antistatic testing and inspection of the production, all procedures are strictly controlled to ensure the static resistant capacity of its chips is up to the requirement. All the products are of good thermal conductivity

ALLTOP -High Lumen Outdoor Ip65 Aluminum Led Gas Canopy Light 100w | Led Canopy Light

ALLTOP -High Lumen Outdoor Ip65 Aluminum Led Gas Canopy Light 100w | Led Canopy Light-1

ALLTOP -High Lumen Outdoor Ip65 Aluminum Led Gas Canopy Light 100w | Led Canopy Light-2

ALLTOP -High Lumen Outdoor Ip65 Aluminum Led Gas Canopy Light 100w | Led Canopy Light-3

Item NO

5025A100-01

5025B120-01

5025C150-01

5025D180-01

Power

100W

120W

150W

180W

Light Source

Bridgelux Chip or Customized

Lamp Size

 350*310*90mm

392*350*90mm

475*350*90 mm

 556*350*9mm

Led Life Span

50000 hours

Color rendering index

Ra≥85

Power factor

PF≥0.96

Rated life≥50000 Hours

Color temperature

3000k-7000k

Working temperature

-30℃~+50℃

Material

High quality Die-casting Aluminium

Input VoltageAC 90-265V 50/60HZ
Beam angle180°
IP codeIP65

Warranty

3yesrs

product description
ALLTOP -High Lumen Outdoor Ip65 Aluminum Led Gas Canopy Light 100w | Led Canopy Light-4

Petrol Station Light

Embedded petrol station light, Easy to install and use. It is suitable for the lighting of large ceilings such as gas stations, underground garages, subway stations, large supermarkets, and large warehouses.

High safety factor,  Moisture proof, anti-corrosion, waterproof, etc.


ALLTOP -High Lumen Outdoor Ip65 Aluminum Led Gas Canopy Light 100w | Led Canopy Light-5

High Quality Led Chip

Imported LED light source, High heat conductivity, low luminous decay, pure light color and no ghosting. Life span longer than 50000 hours.

ALLTOP -High Lumen Outdoor Ip65 Aluminum Led Gas Canopy Light 100w | Led Canopy Light-6

Good heat dissipation performance
The heat From the LED is removed through the heat dissipation wing and also by air ventilation.
ALLTOP -High Lumen Outdoor Ip65 Aluminum Led Gas Canopy Light 100w | Led Canopy Light-7

High quality die-casting aluminum alloy

Made of high quality die-casting aluminum alloy, it has the characteristics of fast heat dissipation, waterproof and anti-corrosion.

Integrative design for heat sink and housing; The LED is closely connected to the surface.

Packing Adventages
ALLTOP -High Lumen Outdoor Ip65 Aluminum Led Gas Canopy Light 100w | Led Canopy Light-8
Attached installation manual
Match installation screw
We use K=K strong yellow carton outer package
Printing the product pictures on the boxes
ALLTOP -High Lumen Outdoor Ip65 Aluminum Led Gas Canopy Light 100w | Led Canopy Light-9
ALLTOP -High Lumen Outdoor Ip65 Aluminum Led Gas Canopy Light 100w | Led Canopy Light-10
Applications


 Led canopy light suitable for the lighting of large ceilings such as gas stations, underground garages, subway stations, large supermarkets, and large warehouses.

ALLTOP -High Lumen Outdoor Ip65 Aluminum Led Gas Canopy Light 100w | Led Canopy Light-11


Company Features
1. The delicate presents the cutting-edge technology of ALLTOP.
2. ALLTOP Lighting is always improving our design and patterns to confirm to the world market. Get an offer!
Contact us
we welcome custom designs and ideas and is able to cater to the specific requirements. for more information, please visit the website or contact us directly with questions or inquiries.
