ALLTOP 150w led high bay light factory for park
1. These unique ideas, styles, and design features will add personality to your led high bay lights.
2. Equipped with superior lamp beads, led high bay lights is soft in light, high in luminous efficiency and excellent in color reproduction. It is free from stroboscopic effect and is harmless to the human eyes.
3. Since the amount of heat produced by traditional lighting is so high, the risk of fire due to overheating is obvious. Luckily, this product does not come with the same risks, since it always remains cool for use.
|
|
| |
Item No | 5025A100-01 | 5025B120-01 | 5025C150-01 |
Power | 100W | 120W | 150W |
Light Source | Bridgelux Chip or Customized | ||
Lamp Size | 350*310*90mm | 392*350*90mm | 475*350*90 mm |
LED Life Span | 50000 hours | ||
Color rendering index | Ra≥85 | ||
Power factor | PF≥0.96 | ||
| Rated life | ≥50000 Hours | ||
Color temperature | 3000k-7000k | ||
Working temperature | -30℃~+50℃ | ||
Material | High quality Die-casting Aluminium | ||
| Input Voltage | AC 90-265V 50/60HZ | ||
| Beam angle | 180° | ||
| IP code | IP65 | ||
Warranty | 3yesrs | ||
Waterproof Led high bay light, Wide range of lighting, Suitable for warehouses, workshops, docks, mines, construction sites, indoor venues etc.
The led chip is a semiconductor chip that emits light and is not easily broken, so that its service life can reach 50000 hours, while the ordinary incandescent lamp has a service life of only one thousand hours.
Made of high quality die-casting aluminum alloy, it has the characteristics of fast heat dissipation, waterproof and anti-corrosion.
Integrative design for heat sink and housing; The LED is closely connected to the surface.
Match installation screw
We use K=K strong yellow carton outer package
Printing the product pictures on the boxes
Led canopy light suitable for the lighting of large ceilings such as gas stations, underground garages, subway stations, large supermarkets, and large warehouses.
Company Features
1. Zhongshan ALLTOP Lighting CO., LTD is a well-known supplier of led high bay lights with large factory and modern production lines.
2. Zhongshan ALLTOP Lighting CO., LTD has obtained many patents in the process of developing 150w led high bay light .
3. We are committed to the environmental sustainability of our operations. We put emphasis on the use of renewable resources and the conservation of water by reducing the water utilization of our factory. We have high-performance work teams. They understand and support the meaning and value of the company's mission and vision. They connect their roles and responsibilities to enhance team potential and thereby enhance company competence. Practicing sustainable development is how we fulfill our social responsibility. We partake in social charitable giving, volunteer in serving the communities, and helping build village schools.
| Power | 50W | 80W | 100W | 150W | 200W |
Input Voltage | AC85V-277V,50-60Hz | ||||
Color Temperature | 2700k~3500K;4000k~4500K;5000k~7000K | ||||
Power Factor | >0.9 | ||||
Beam Angle | 25/60//110° | ||||
Base Type | Tube/Hook/Bracket | ||||
Diffuser | PC lens | ||||
| Luminous Flux | 5500-6500lm | 8800--9500lm | 11000- 12000lm | 16500-17500lm | 21000-22000lm |
Operate Temperature | -20℃~+50℃ | ||||
CRI | >80 | ||||
Life Span | 50000 hrs | ||||
IP grade | IP54 | ||||
| Housing Color | Silver | ||||
Size | 345*322mm | 345*322mm | 345*342mm | 345*372mm | 345*422mm |
Detail Show
Features:
l Aluminum Extrusion profiles radiator, thermal faster with copper pipe inside ; Charming heat dissipation design
l led branded chip LED source, high stability and color rendering
l Meanwell driver, Old brand with quality assurance
l Reflector with anti-glare design which highly reduced the light glare problems.
l 45 ° / 60 ° / 90 ° / 120 ° optional beam angle.
Midle Size and Reflector Size:
Installation and instructions:
