We are a leading manufacturer of solar power utilization and lighting systems

All in one solar led street light

High quality IP67 waterproof all in one solar led street light

Certification:

CE/ISO9001/RoHS/3C/CQC//UL/TUV

Delivery Time:

5-15 days

Payment Terms:

L/C, D/A, D/P, T/T, Western Union, MoneyGram

Service:

OEM/ODM Customized　

Start Port:

guangzhou ,shenzhen, zhuhai

Supply Ability:

5000 PCS/Month

Inquiry

Write a Review


Item No	0845A30-01	0845B60-01	0845C90-01	0845D120-01	0845E150-01
Power	30W	60W	90W	120W	150W
LED Lamp	30W LED 3000K-6000K	60W LED 3000K-6000K	90W LED 3000K-6000K	120W LED 3000K-6000K	150W LED 3000K-6000K
Lamp Size	40023065 mm	53024065 mm	64525065 mm	75025065mm	83825065 mm
Solar Panel	6V 5.5W, Polycrystalline	6V 8.5W, Polycrystalline	6V 11.5W, Polycrystalline	6V 18W, Polycrystalline	6V 22W, Polycrystalline
Battery Type	LiFePO4 3.2V 12AH	LiFePO4 3.2V 18AH	LiFePO4 3.2V 24AH	LiFePO4 3.2V 30AH	LiFePO4 3.2V 36AH
Charging time	6-8 hours
Discharging time	30-36 hours
Lumen	160lm/w
Material	ABS
Install Height	3-5m	4-6m	5-8m	5-10m	5-12m
Warranty	3years

product description

product-ALLTOP -All in one solar led street light-img

All-in-one Solar Street Light

All-in-one design and charged by solar, so the lighting kits are completely wireless and easy to be mounted. Widely arrange mount applications on wall, fence, tree, steps, etc. to light up your garden, hallway, flowerbeds, pillar, deck, yard, patio, or driveway and any other places.

High Quality LED Chip

The LED chip is a semiconductor chip that emits light and is not easily broken, so that its service life can reach 50,000 hours, while the ordinary incandescent lamp has a service life of only one thousand hours.

Polysilicon solar panel

Polycrystalline silicon solar panels, which are easier to manufacture, save power, and have low overall production costs.

Positive power tolerance: 0~+ 5W

100% EL double-inspection ensures modules are defects free

Modules binned by current to improve system performance

Human induction

Human body infrared light
Strong light environment (daytime) does not light up!
In the low light environment or at night, the sensor body detects the change of infrared heat energy caused by the movement of the human body and then triggers the lighting. Sensing diameter is farther and more sensitive.

IP65 waterproof rating

Simple operation, easy to use, automatic lighting at night, safer, more durable, more fashionable.

product-All in one solar led street light-ALLTOP -img-1

ABS

Made of high-impact ABS material, this solar light is IP65 waterproof so it can withstand rain and other extreme weather conditions
ABS material is clean and environmentally friendly, tasteless and odorless, harmless to the human body and in line with health and safety. It has excellent physical and mechanical properties such as high heat resistance, good transparency and high impact resistance.s.

Features

product-ALLTOP -All in one solar led street light-img-1

When anyone passes by, it will be 100% brightness.
When people passes away, it will be 30% brightness.
Full charge time: About 6-8 hours under direct sunshine
Discharge time on a full charge: 20-24 hours
◪ Very easy to install,
◪ Provide bright and wide beam distribution light for general purpose flood night lighting.
◪ Energy-saving and Eco-friendly, no any pollution to environment.
◪ High efficiency, low light decay.
Note:
◪ Charge under direct sunlight for 6 to 8 hours
◪ Turn on the switch after installation
◪ Please choose a position without any shelter for enough sunshine and fully exposure

◪ After turn on the light, first it will flash then light, which is normal.

Lithium battery advantages

01

Green and environmental protection: no toxic heavy metal substances such as lead, mercury and cadmium are produced.
02

Lithium-ion battery can be charged and discharged at any time, unlike nickel-metal hydride, nickel-tin battery, must wait until the power is exhausted.
03

The environmental temperature difference changes adaptability: can be used in the environment of -20 ° C ~ 60 ° C,

ALLTOP -Find Solar Lamp Solar Powered Street Lights From Alltop Lighting-10

04

Production basically does not consume water, which is very beneficial to countries where water sources are scarce.
05

Lithium battery voltage platform is high: the average voltage of the single battery is 3.2V or 3.7V, which is convenient for forming a battery pack.
06

The service life is relatively long: the service life can reach more than 6 years

Showroom

Using package color inner boxes
Attached installation manual
Match installation screw
We use K=K strong white carton outer package
Printing the product pictures on the boxes

Applications

product-All in one solar led street light-ALLTOP -img-2
