PRODUCT ATTRIBUTE
| Item NO. | DQ1400F1K5-01 |
| Battery Rated Voltage | 12VDC |
| Rated Power | 1500W |
| Input Voltage Range | 160-275VAC |
| Input Frequency | 45-65Hz |
| Output Voltage | 220VAC |
| Output Frequency | 50Hz/60Hz |
| Output Wave | Sine Wave |
| Internal Battery Bank | 1*60AH/12VDC |
| Solar Panel Specification | 200W 18V |
| Communication | RS232 |
| Max .PV Voltage | ≤25VDC |
| Range Of Charging Voltage | 10-25VDC |
| Rated Charge Current | 20A |
| Voltage For Overcharge Protection | 14.2VDC |
| Voltage For Overcharge Recovery | 14.0VDC |
| Voltage For Floating Charge | 13.7VDC |
| Voltage For High Voltage Protection | 16V |
| High Voltage Recovery Voltage | 15.2V |
| Low Voltage Recovery Voltage | 12.6V |
| Low Voltage Protection Voltage | 11VDC |
| 5VDC USB Output | 2PCS/MAX 2A |
| 12 VDC Output Ports | 2PCS/MAX 2A |
| Heat Dissipation/Cooling | Temperature Control By Intelligentexhaust Fan |
| Operating Ambient Temperature | -20-+50℃ |
| Storage Ambient Temperature | -25-+55℃ |
| External Size | 513*310*493mm |
| Packing Size | 610*420*550mm |
