High brightness IP67 waterproof all in one solar 20w led street light

High brightness IP67 waterproof all in one solar 20w led street light

Price
Get Latest Price
Get the latest price
Quantity Needed:
Pieces
E-mail:
Overview
Quick Details
Place of Origin:
Guangdong, China
Brand Name:
ALLTOP
Model Number:
0330B20-02
Application:
Garden, garden, courtyard, road, outdoor, etc.
Power Supply:
Solar
Type:
High brightness IP67 waterproof all in one solar 20w led street light
Solar panel:
17.1W 15V , Mono-crystalline
Size:
468*430*398mm
power:
20w
Lampshade Material:
High quality aluminum alloy, aluminum alloy
Charging time:
6-8 hours
Discharging time:
>15 hours
Install Height:
3-5M
Warranty:
3 years
Supply Ability
Supply Ability:
2000 Piece/Pieces per Day



High brightness IP67 waterproof all in one solar 20w led street light



PRODUCT ATTRIBUTE

Item No.

0330B20-02

Dimension

468*430*398mm

Solar panel

15V 17.1W(Mono)

Power

20W

Luminous flux

2000lm

LED Lamp

20W LED 6000K-6500K

Charging time

6-8 hours

Discharging time

>15 hour

Material

aluminum alloy

Light efficiency

100lm/W

IP code

IP65

Battery

Lithium-Ion 12V 8AH

Certificate

CE, ROHS, SAA,TUV, EMC, LVD

Application

Garden, courtyard, road, outdoor, etc.

Install height

3-5m

Warranty

3 years





Product Description

   More detail information, please just feel free to contact us.

Product Features:

1.“All in One solar steer light ” could not work without sunshine, please select the suitable model according to the local sunshine radiation and the annual total radiation. We suggest use the both AC and DC charging model in those places where lack of sunshine or have long-time rainy days.



2.“All in One solar street light” adopts the long life Lithium battery for storing energy, charging temperature at day time is between: 0~+60, when temperature goes lower than 0, the control system will stop automatically to protect the battery, and it will revive to charge the battery while temperature goes higher than 0. Discharging temperature at night is between: -20~+60, any ambient beyond will take damage to the battery. So please check these factors while selecting the street light.





3.Battery of the All in One solar street light” can be stored for 6 months long after fully charged.Therefore please examine and charge it periodically after long time transportation or storage to prevent damaging.



4.When install the lights in Northern Hemisphere, please adjust the solar panel to the South as much as possible to collect maximum sunshine radiation, while install them in Southern Hemisphere, By the same token, keep solar panel to north. At the same time please keep it away form any shadow of houses, trees etc.



5.Keep clear of the surface of the All in One solar street light with normal detergent to get maximum power generation, clear the dust or tree leaves or any grease.



6.All in One solar street light have got the standard of IP65. The vents on the surface is designed for radiating. The materials are made of aluminum alloy which can survive in the environment of seaside and desert.



7.The knob of the fuse is at the left rear end of the light, please insert the fuse while using. By the way, there is one piece of fuse more as backup(If not fuse, then it is switch, just turn the switch)







Packaging & Shipping



Company Information
Zhongshan ALLTOP Lighting CO., LTD is strong in technology, advanced equipment and quality assurance system. The product has a color rendering index which reaches over 70Ra. To meet the needs of customers who pursue high-quality LED street lights, ALLTOP has successfully made it. The product has a color rendering index which reaches over 70Ra.
